Revolutionary Design Thinking
To create an aero bike that controls airflow, Bianchi borrowed ideas from innovative technology sectors, including automotive, aerospace and architecture. The goal is to lead the air to very specific areas of the frame, ensuring airflow is as close to the surfaces of the bike and rider as possible. The far-thinking design is enhanced by a judicious balance of paint and exposed carbon, creating a fearsome racing aesthetic that never for a second compromises on the overall weight of the Oltre.
The Oltre is also equipped with the best Velomann components: Aero handlebar and stem, wheels and saddle.
Leading the way in aerodynamics
The Oltre was developed using advanced Computational Fluid Dynamics (CFD) simulation software to predict the effects of drag and was wind tunnel tested.
Each movement refined
Each detail of the Oltre is considered, analysed and refined, amplifying the efficiency and power of every pedal stroke. From the down tube to the seat post to the dropouts, every marginal gain has been harnessed.
TECH SPECS
FRAME
Oltre Comp, carbon, disc brakes, electronic and mechanical shifting compatible, internal cable routing 1.5-1.5 headset, BB-PressFit 86,5x41, flat mount brakes, thru axle 12x142mm, sizes 47-50-53-55-57-59cm
FORK
Full Carbon aero, Disc brakes, integrated head 1.5, flat mount caliper, thru axle 12x100mm
HEADSET
Fsa TH-073E ACB 1.5 51.8x40x8
SHIFTERS
Sram RIVAL ETAP AXS D1 Hydraulic Disc Brake
REAR DERAILLEUR
Sram RIVAL ETAP AXS D1 MAX 36T
FRONT DERAILLEUR
Sram RIVAL ETAP AXS D1
CRANKSET
Sram RIVAL D1 DUB, 48/35, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm
BOTTOM BRACKET
Sram Press fit Road 86,5x41
CHAIN
Sram RIVAL D1 12S
CASSETTE
Sram CS XG 1250 D1 10-36T
BRAKES
Sram included in the shifter
ROTOR
Sram Centerline, centerlock 160mm front and rear
WHEELS
Velomann Plutonium, 50mm profile, 700x21c, 24h, XDR body
TIRE
Vittoria Rubino 28-622 full black G2.0, graphene + silica, 100TPI
STEM
Velomann Aero stem, material alloy, Oversize, 1.1/8, size: 90mm-47/50cm, 100mm-53cm, 110mm55/57cm, 120mm-59cm
HANDLEBAR
Velomann Aero Compact handlebar, alloy diam. 31,8mm, reach 74mm, drop 116mm, for fully internal cable routing Size: 400mm-47~53cm, 420mm-55~59cm
GRIPS / EXTENSIONS
Bianchi Arrow premium tape, 2.5mm thickness, black
SEATPOST
Oltre Full Carbon Aero special dimension seatpost, 20mm offset, length: 280mm-47cm, 300mm-50~55cm, 350mm-57~59cm
SADDLE
Velomann Mitora139, open flow, AISI rails 7x7mm, carbon-reinforced nylon, Wide: 139mm, Lenght: 250mm
