TECH SPECS

FRAME

Oltre Comp, carbon, disc brakes, electronic and mechanical shifting compatible, internal cable routing 1.5-1.5 headset, BB-PressFit 86,5x41, flat mount brakes, thru axle 12x142mm, sizes 47-50-53-55-57-59cm

FORK

Full Carbon aero, Disc brakes, integrated head 1.5, flat mount caliper, thru axle 12x100mm

HEADSET

Fsa TH-073E ACB 1.5 51.8x40x8

SHIFTERS

Shimano Ultegra Di2 hydraulic disc brake for road, ST-R8170, BR-R8170, for 160mm rotor

REAR DERAILLEUR

Shimano Ultegra Di2 12sp, RD-R8150

FRONT DERAILLEUR

Shimano Ultegra Di2 12sp, FD-R8150

CRANKSET

Shimano, Ultegra 12sp, FC-R8100, for rear 12- speed, 52x36T, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm

BOTTOM BRACKET

Shimano, SM-BB72-41B, press fit for road, bearing, inner cover

CHAIN

Shimano, Ultegra 12 sp, CN-M8100

CASSETTE

Shimano Ultegra, CS-R8100, 11-12-13-14-15-16-17-19- 21-24-27-30T

BRAKES

Shimano BR-R8170 Hydraulic disc brake, included in the shifter

ROTOR

Shimano, centerlock type w/Ice Tech, 160mm front and rear

WHEELS

Velomann Plutonium, 50mm profile, 700x21c, 24h, HG body

TIRE

Vittoria Rubino 28-622 full black G2.0, graphene + silica, 100TPI

STEM

Velomann Aero stem, material alloy, Oversize, 1.1/8, size: 90mm-47/50cm, 100mm-53cm, 110mm55/57cm, 120mm-59cm

HANDLEBAR

Velomann Aero Compact handlebar, alloy diam. 31,8mm, reach 74mm, drop 116mm, for fully internal cable routing Size: 400mm-47~53cm, 420mm-55~59cm

GRIPS / EXTENSIONS

Bianchi Arrow premium tape, 2.5mm thickness, black

SEATPOST

Oltre Full Carbon Aero special dimension seatpost, 20mm offset, length: 280mm-47cm, 300mm-50~55cm, 350mm-57~59cm

SADDLE

Velomann Mitora139, open flow, AISI rails 7x7mm, carbon-reinforced nylon, Wide: 139mm, Lenght: 250mm

• Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
